DC COUPLING

MPPT Solar Charger 1500Vdc

PV DC Coupling — MPPT 1500Vdc — 98% Efficiency

Power Range
50–150 kW
Efficiency
98%
Voltage
1500 Vdc
Models
8 models

Overview

The LEONICS MPPT Solar Charger 1500Vdc is a newer model for direct DC-coupled PV systems, connecting solar to battery without two stages of AC inversion, at 98% efficiency.

Key Features

  • ✓Eight models — SCM-501000, SCM-1001000, SCM-1501000, SCM-12501500 and SCB-501000, SCB-1001000, SCB-1501000, SCB-1251500
  • ✓Rated 50, 100 and 150 kW, plus a 125 kW model in the 1500 Vdc class · maximum power 55, 110 and 165 kW
  • ✓One to three MPPTs by rating · up to 160 A PV input per MPPT on SCM, 110 A on SCB
  • ✓1500 Vdc models take 500–1,450 Vdc of PV into a 550–1,500 Vdc battery · 1000 Vdc models work across 200–950 Vdc
  • ✓Up to 98% maximum efficiency
  • ✓DC coupling connects the array straight to the battery DC bus — no separate solar inverter and no second AC conversion stage
  • ✓IP20 cabinet for indoor installation, IP44 for outdoor
  • ✓483 mm rack width · 30, 60 or 90 kg depending on rating

Configurations

SCM-345160

  • Power: 50 kW
  • PV Voltage: 200–900 Vdc
  • Battery Voltage: 250–950 Vdc

SCM-320

  • Power: 100 kW
  • PV Voltage: 200–900 Vdc
  • Battery Voltage: 250–950 Vdc

SCM-480

  • Power: 150 kW
  • PV Voltage: 200–900 Vdc
  • Battery Voltage: 250–950 Vdc

SCB-500110

  • Power: 50 kW
  • PV Voltage: 250–950 Vdc
  • Battery Voltage: 200–900 Vdc

SCB-220

  • Power: 100 kW
  • PV Voltage: 250–950 Vdc
  • Battery Voltage: 200–900 Vdc

SCB-330

  • Power: 150 kW
  • PV Voltage: 250–950 Vdc
  • Battery Voltage: 200–900 Vdc

Who makes it, who sells and installs it

  • LEONICS — manufacturer — MPPT Solar Charger 1500Vdc is designed and manufactured by LEONICS Co., Ltd., building power electronics since 1991 at its factory in Wellgrow Industrial Estate, Chachoengsao.
  • Contact LEONICS — Tel +66 2-746-9500 · rne@leonics.com — for system design, quotations and customers outside Thailand
